General purpose AF jointings sheet suitable for use in low pressure steam, oils, gases, water, air, waste-water, light industrial and domestic applications.
Available with guage wire insertion.
Also available with anti-stick coating or graphite coating.
Max. short term service temp. : 380°c
Max. continuous service temp. : 240°c
Max. operation temp. for steam : 170°c
A good quality general purpose jointing material developed for low stress conditions. Suitable for complete sealing of low pressure steam, water, air, gases and various mild alkaline chemicals.
Can be used in Automative / Light Industrial and Domestic Application.
Available with guage wire insertion.
Also available with anti-stick coating or graphite coating.
Max. short term service temp. : 400°c
Max. continuous service temp. : 250°c
Max. operation temp. for steam : 180°c
For wide range of Industrial applications.
Recommended for medium pressure steam, gases, water and dilute chemicals, oil and solvents.
Available with gauge wire insertion.
Also available with anti-stick coating for graphite coating.
Max. short term service temp. : 400°c
Max. continuous service temp. : 250°c
Max. operation temp. for steam : 190°c
AF jointing sheet for applications in hydrocarbons, such as oils and solvents and general purpose use in water, steam, gases, dilute acids and alkalis, glycols, and aqueous solutions.
Available with guage wire insertion.
Also available with anti-stick coating or graphite coating.
Max. short term service temp. : 400°c
Max. continuous service temp. : 250°c
Max. operation temp. for steam : 200°c
For use with oils, solvents, gases, steam, dilute acid & alkalies.
Excellent tensile strength.
Outstanding gas sealability.
High resistance to creep under elevated temperatures & pressures.
Available with guage wire insertion.
Also available with anti-stick coating or graphite coating.
Max. short term service temp. : 450°c
Max. continuous service temp. : 250°c
Max. operation temp. for steam : 250°c
High resistance to hot oils, fuels, hydrocarbons and refrigerants.
Good steam resistance.
Excellent creep resistance.
Very low gas permeability.
Available with gauge wire insertion.
Also available with anti-stick coating or graphite coating.
Max. short term service temp. : 450°c
Max. continuous service temp. : 250°c
Max. operation temp. for steam : 250°c
Acid resistance grade.
Recommended for use against hot concentrated organic, inorganic and mineral acids.
Resistance to Alkalis, Ketones, Aldehydes.
Resistant to Hydrocarbons, fuels and refrigerants.
Also available with anti-stick coating or graphite coating.
Max. short term service temp. : 250°c
Max. continuous service temp. : 210°c
Max. operation temp. for steam : 210°c
