A unique interbraided packing manufactured from pure graphite fibre with excellent heat dissipating properties and chemical resistance.
Service Media : Strong acids and alkalies, solvents, fuel and lube oils, super heated and saturated steam, bitumen, SO2etc.
Working Condition : Temp.850°C, Pressure 400 KCS, PH range 0 to 14.
Pure PTFE fibre interlock braided packing without having any additives.
Service Media : Food stuff, oxygen services, ammonia, carbomate solution, strong/weak acid and alkali etc.
Working Condition : Temp. -200°C to +260°C, Pressure 500 KCS, PH range 0 to 14.
Pure PTFE interlock braided packing incorporating break in lubricant having high cross sectional density.
Service Media : Corrosive gases, acids, ammonia, caustics, solvent etc.
Working Condition : Temp. -200°C + 260°C, pressure 500, KCS PH range 0 to 14.
Pure PTFE filament interlock braided packing incorporting antifrictional inert lubricant.
Service Media : Acids and alkali, oils and any corrosive chemicals except flourine and molten alkali metal.
Working Condition : Temp. -200°C to +250°C, pressure 200 KCS, PH range 0 to 14.
Interlock braided Aramid/KEVLAR fibre braided packing incorporating break in lubricant and special flouropolymer.
Service Media : Crystalline chemical slurries, ash slurry, and abrasive media, oil wood pulp, brines, organic solvents, hydrocarbon, sewage and hot water, coal and iron dust etc.
Working Condition : Temp. -200°C to +300°C, pressure 500 KCS, PH range 1 to 13.
Pure carbon filament interlock braided packing firmly entrapping fine graphite flake as blocking agent to stop leakage.
Service Media : Acids, oils, solvents, superheated steam etc.
Working Condition : Temp. 550°C, pressure 180 KCS, PH range 0 to 14.
Cross Braided combination packing manufactured from pure PTFE fibre and pure graphite fibre.
Service Media : Corrosive and non corrosive gases, acids, oils, alkali solutions, oleum etc.
Working Condition : Temp. 450°C, pressure 450 KCS, PH range 0 to 14.
PTFE intemately bonded with graphite packing in interlock braid.
Service Media : Caustics, acids, dyes and chemicals etc.
Working Condition : Temp. -200°C to +250°C, pressure 100 KCS, PH range 0 to 14.
Interlock braided PTFE graphite solid yarn dense packing manufactured in single molecular structure.
Service Media : Mercury, acids and alkali, dyes and chemicals, oil and solvent, white and black liquor bitumen, boiler feed water, hydrocarbon, hypo etc.
Working Condition : Temp. -200°C to 300°C, pressure 180 KCS, PH range 0 to 14.
Flexible pure graphite compresses and die-moulded preformed gland packing ring in endless form/two halves in oblique cut having 99% to 99.8% carbon.
Service Media : Saturated and superheated steam, oil, solvent, hydrocarbon etc.
Working COndition : Temp. -250°C to +600°C (+3000°C in non oxydising media), Pressure 300 KCS, PH range 0 to 14.
Cross braided packing manufactured from combination of Aramid/KEVLAR fibre and graphited PTFE fibre.
Service Media : Mercury, alkaline solution, hot water, MILED abrasive media, critical chemical compound, green liquor etc.
Working Condition : Temp. -200°C to +300°C, pressure 250, KCS PH range 1 to 13.
Perfect combination inter braided packing having graphited PTFE yarn as its base and aramid/KEVLAR yarn at the edges.
Service Media : Black and green liquor, sewage water, oil, weak acid and alkali etc.
Working Condition : Temp. -200°C to +300°C, pressure 250 KCS, PH range 1 to 13.
Interlock braided packing having pure PTFE fibre at the face and aramid/KEVLAR fibre at the corner.
Service Media : Carbomate solution, ammonia and ammonium compound, trisodium phosphate, DMT and host of critical chemicals used in petrochemical industries.
Working Condition : Temp. -200°C to +260°C, pressure 500 KCS, PH range 1 to 13.
Is pre-compressed Gland Packing Ring manufactured from high purity (99.5% to 99.9% Carbon) Flexible Pure Graphite Foil. This packing is free from any contamination and does not contain oil or grease or additives or any kind of binder. This ia a universal packing for pumps and valves and is capable of handing the widest range of service media. Specific density of the packing is maintained for compression resistance and retention of size and shape.
Working Condition : Temp. -250°C to +600°C (Steam) 450°C (Oxidising Media) 3300°C (Non-Oxidising Media) pressure 300 KCS PH range 0 to 14.
Glass fibre yarn, Twisted rope round & Square section, Cloth , Tape, Gland Packing lubricated &Graphited.
Working Temperature: -240°C to 550°C
Pressure: Upto 200 bar
PH Range: 0 to 14
We also offer SUPERSEAL 995 Glass FibreGland Packing Impregnated with PTFE Dispersion for General valve / Static Seal Packing.
Service Media: It has superior thermal resistance, Good Strength low co efficient of friction, Tensilestrength, Chemical Resistance.
Working Temp: 100 Deg C to 250 Deg C
* Superseal packings are availabe in rope form as well as in preformed ring in oblique cut. *
Specially developed Non-Graphited Tough Vegetable Fibre Yarn braided packing lubricated with special dry lubricants suitable for Marine application. This packing is highly antifrictional and resistant to rot hence recommended for Sea water, River water, Fresh water application. This is also extremely suitable for Wheel Shaft, Rudder Post and Stern Gland application. Temp. Range - 130°C
A tough Vegetable Fibre Yarn braided Gland Packing incorporated with special Fluoro-Polymer, most reliable packing for Shipping, particularly for Stern Tube and Rudder Post. This is highly recommended packing for Sea Water application too. Temp. Range - 150°C.
This braided packing is manufactured from tough and strong Vegetable Fibre Yarn Impregnated with Special lubricant incorporating ant-frictional fine Graphite Flake recommended for Fresh and salt water, Pen-Stock of Hydel Power Station and heavy duty Hydraulic application. Temp. Range - >130°C.
A fine natural Soft Fibre Yarn braided packing thoroughly impregnated with high grade Fluoro-Polymer Lubricant specially developed for Centrifugal Pumps handling Dimineralised water, Cooling water and Condensate. Temp. Range - 130°C.
A fine soft Vegetable Fibre Yarn Self-Lubricated braided packing specially impregnated with Graphite incorrporating 'Break in Lubricant' recommended for Pumps and Valves handling Dimineralised water, Cooling water, Condensate and also for Hydraulic application. Temp. Range - 150°C.
A special soft Vegetable Fibre Yarn braided pcking impregnated with dry lubricant and Graphite specially developed for Reciprocating / Rotary Pump, Valve and Compressor. This Naturl Fibre of the packing has got inherent tendency to absorb Fluids in operation and hence maintains smooth and soft relation between the packing and the parent equipment which ultimately prevents shaft and sleeve erosion. Temp. Range - 130°C.
